| Common specifications | |||||||||||
| Power supply | DC24V ±15％ | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Output range | ±10V DC Load resistance must be more than 5kΩ | ||||||||||
| Responsivity | 5kHz | ||||||||||
| Rotationsignal | 4 pulses per 1 rotationOpen collector Max. ratings 30V, 10mA | ||||||||||
| Digital filter | 1Hz~1kHz(Depending on settings) PASS 5kHz | ||||||||||
| Safe overload | 500%FS | ||||||||||
| Non-linearity | 0.03%FS | ||||||||||
| Hysteresis | 0.03%FS | ||||||||||
| Repeatability | 0.03%FS | ||||||||||
| Operationtemp . range | －10 to ＋50℃ | ||||||||||
| Temp. effecton ZERO | 0.01%FS/℃ | ||||||||||
| Temp. effecton span | 0.01%FS/℃ | ||||||||||
| Supplied cable | 12-core shielded cable(2m), cable end separated（Cable length is switchable to 5m（Option：UTMⅢ-L5）） | ||||||||||
| Optionally available cable | CATM351：12-core shielded cable(5m), cable end separatedCATM312：12-core shielded cable(10m), cable end separated | ||||||||||
| CE markingcertification | EMC directives EN61326-1,EN61326-2-3 | ||||||||||
