| Model | IBG20 (Without adjuster) |
IBG21 (With adjuster) |
| Fluid | Air | |
| Max. operating pressure | 0.7 MPa | |
| Proof pressure | 1.05 MPa | |
| Fluid and ambient temperature range | +5 to +60°C | |
| Operational force | 10 N or less | |
| Weight*1 | 300 g | 320 g |
| Series | Peak pressure | Size (Height x Depth x Width) [mm] |
Weight [g] |
Tank capacity [cc] |
Air consumption∗2 [cc] |
Supply port |
|---|---|---|---|---|---|---|
| IBG1 High Peak Pressure Type |
3 times or more |
183.8 × 83 × 41 | 380 | 100 | 600 | Screw-in type (Rc, NPT, G) 3/8 One-touch fittings ø6 to ø10 ø1/4" to ø3/8" S coupler R3/8 |
| IBG2 Compact Type |
2.5 times or more |
174.5 × 76 × 41 | 300 | 70 | 420 | Screw-in type (Rc, NPT, G) 1/4 One-touch fittings ø6 to ø10 ø1/4" to ø3/8" S coupler R1/4 |
| Compared with the existing VMG series model |
The amount of air filled in the tank at 0.5 MPa operating pressure |
