| Series | Set pressure | Applicable tubing size | Type |
|---|---|---|---|
| PPA100 | －0.1 to 1 MPa | φ4，φ6 | For high pressure |
| PPA101 | －101 to 10 kPa | φ4，φ6 | For vacuum |
| PPA102 | －10 to 100 kPa | φ4，φ6 | For low pressure |
| Model | PPA100 for high press | PPA101 for vacuum | PPA102 for low press | |
|---|---|---|---|---|
| Rated pressure range | －0.1 to 1 MPa | －101 to 10 kPa | －10 to 100 kPa | |
| Display method | 3 digit LCD back light | |||
| Pressure display discrimination | 1/100 | |||
| Min. display units |
kPa | - | 1 | 1 |
| MPa | 0.01 | - | - | |
| mmHg | - | 5 | - | |
| kgf/cm2 | 0.1 | 0.01 | 0.01 | |
| inHg | - | 0.2 | - | |
| psi | 1 | 0.1 | 0.1 | |
| bar | 0.1 | 0.01 | 0.01 | |
| Error display | Over pressure, Memory data error, Change battery sign | |||
| Function | Peak/bottom display, Backlight, Auto power OFF Zero clear, Units display switching | |||
| Withstanding pressure | 1.5 MPa | 200 kPa | 200 kPa | |
| Applicable fluid | Air, Non-corrosive gases, Nonflammable gas | |||
| Power supply voltage | 3 VDC, Type AA dry cell x 2 pcs. | |||
| Battery life | 12 months continuous operation (Without backlighting, temperature conditions: at 25°C) | |||
| Response speed | 250 ms | |||
| Display accuracy | ±2% F.S. or less (Temperatue conditions: at 25°C) | |||
| Repeatability | ±1% F.S. or less (Temperatue conditions: at 25°C) | |||
| Temperature characteristics | ±3% F.S. or less (0 to 50°C with 25°C standard) | |||
| Connection port size | M5 x 0.8 | |||
| Operating temperature range | 0 to 50°C (With no condensation) | |||
| Operating humidity range | 35 to 85% RH (With no condensation) | |||
| Enclosure | IP40 | |||
| Weight | Approx. 100 g (Unit 50 g, batteries 50 g) | |||
| Standard | CE/UKCA Marking | |||
