| Model | MCR-F600 |
| Interface | RS-232C, Ethernet (10 Base-T, 100 Base-T) |
| Supported barcodes (2D) | DataMatrix(ECC200), PDF417, MaxiCode, QR Code, MicroQR, MicroPDF, GS1 Data Bar Composite, Customer barcode (optional), Vericode (optional) |
| Supported barcodes (1D) | JAN/EAN/UPC, ITF, Codabar, Code39, Code93, Code128, EAN128, GS1 Data Bar, Customer barcode (optional), |
| Minimum resolution | Depends on lens |
| Power supply | DC12.0V/24.0V +/-10% |
| Power consumption | 0.5A @12.0V, 0.25A @24.0V |
| Operating temparature/Humid | 0 to 40C / 35 to 85%RH (no condence) |
| Storage temparature/Humid | -20 to 60 C / 35 to 85%RH (no condence) |
| Digital input | Photocoupler isolation x 1, Resistance: 2.2kΩ, OFF voltage: 0 to 0.8V, ON voltage: 10.8 to 28V |
| Digital output | Photocoupler isolation x 3, Rated value DC30V 50mA |
| Dimensions | 49(W) x 51(H) x 87(D)mm |
| Weight | 280g |
